YDJ series colposcopes are the precise optical instruments specializing in gynecology examination and diagnose. Vagina lesion could be observed clearly which could not be seen by naked eye through the instruments because of its magnification. It improved the precision of the diagnose. Clear image, wide field, even illumination, and convenient usage are the characteristic of YDJ series colposcopes. It is the necessary instruments for gynecology examination.
SPECIFICATION & STANDARD OUTFITS
Parameters/Model | YDJ-Z |
Observation angle | 45°inclined binocular tube |
Magnification of eyepiece | 10X |
Rang of Papillary distance | 50mm-80mm |
Diopter adjustment range | ±7D |
Large objective lens | F=300mm |
Magnification changer | Continuous zoom magnification：0.4X-2.75X， |
Total magnification | 2.5X-16.7X |
Linear field | 13mm-80mm |
Beam splitter | 5:5 Beam splitter |
Camera adapter | compatible with c-mount 1/3" CCD camera |
Illumination system | 10W Coxial LED illuminator with brightness adjustment. Illumination >25,000LX. life time is over 50,000 hours |
Filter | Built-in green and blue filer |
Balanced arm | Adjustable and resttable weight |
Stand | 5-star base |
Input power | Adapter output：DC12V/3A；Power：36W； |
Weight per unit | 48KG 2CTNS/SET |
